New Software Creates Heat Sink Geometries

July 5th, 2016

By

From Cradle, HeatDesigner is a fast, efficient, and easy to use thermal analysis tool for electronics cooling. It includes a one time saving feature, a Parametric Study Tool, and plate heat sink creation. With a few inputs, the shape of pin or plates fins, and their orientation and spacing are quickly created. HeatDesigner models can contain 100 million elements so the flow field details are accurately captured.

heatdesign

Image courtesy, Cradle.
